Specifications
Display
| Size / Panel Type |
21.5” TFT LCD Panel |
|---|
| Resolution |
1920 x 1080 |
|---|
| Brightness (cd/m²) |
250 cd/m² (Optional: 1000 cd/m²) |
|---|
| Contrast Ratio |
5000:1 |
|---|
| Response Time |
25 ms |
|---|
| Backlight |
LED Backlight Unit |
|---|
| Colors |
16.7M colors |
|---|
| Viewing Angles |
178°/178° |
|---|
Touch Screen
| Touch Screen (Optional) |
P-CAP Touch |
|---|
| Surface Hardness |
7H |
|---|
Environment
| Operating Temperature |
0°C~+50ºC |
|---|
| Storage Temperature |
-20˚C~+60˚C |
|---|
| Humidity |
10%~95% RH(Non-Condensing) |
|---|
| Water-Proof Rating |
IP65 Waterproof Front Bezel |
|---|
Mechanical
| Mounting |
VESA 75 x 75mm; 100 x 100mm |
|---|
| Dimension/Weight |
528mm (W) x 342.3mm (H) x 79mm (D) / 9.5Kgs |
|---|
| Housing Material / Color |
Metal / Black |
|---|
Power
| Power Input |
AC100~240V Input |
|---|
| Power Consumption |
130W |
|---|
System
| Processor |
Intel® Core™ i7-7700 Processor |
|---|
| I/O Interface |
USB x 4, HDMI x 1, DVI x 1, LAN x 2, DC in x 1 |
|---|
| Certification |
FCC/CE/RoHS Compliance |
|---|
FSP2260-5P-7700
